MATADOR MDE with JACK
MATADOR MDE with JACK

Deck Oven MATADOR MDE with JACK

with JACK, the manual loader

THIS IS UNIQUE! FULL STEAM AHEAD!
75 % relative humidity in one minute. Rich steam for real batch-on-batch baking.This is achieved by the powerful pipe vapor system of the MATADOR® MDE. The vapor draft ensures fast vapor removal from the baking chamber – for perfect crispness of even vapor-sensitive pastry.

HIGH OVEN CHAMBER FOR BREAD! Best baking quality from the MATADOR® deck oven finally also in the retail area or in any building without flue connection. MATADOR® MDE makes it possible! Thank to its high baking chambers it can also be used for baking bread – of premium quality, of course.

CLEVER DESIGN!The MATADOR® MDE also fits into rooms with low ceiling height since it does not require piping for flue connection. Thanks to its moveable frame it is independent of its installation site and it can be installed on 3 sides. Move it around comfortably for maintenance work and its outer body will move along. This is quite handy!



  • Smart Control – easy and standardized operation for WP machines
  • GreenEnergy – minimal Energy, maximal Efficiency
  • BakingQuality – Baking with unique quality

BENEFITS

  • Easy operation
  • WP INTELLIGENT ENERGY CONTROL
    - Minimizing the energy loss during baking breaks through Standby function with controlled temperature reduction
  • Special baking stones for stone-baked bread
  • Proven MATADOR® baking quality
  • 4 to 6 ovens
  • Baking area from 4 to 8 m²
  • Each oven can be controlled and switched off separately
  • Vapor-tight welded baking chamber
  • No crust burning
  • Perfect crispness, even with vapor-sensitive pastry
  • Mobile thanks to garage concept
  • Flue-Idependent (optional)
  • Radiant heat thanks to concealed heating elements
  • Separate vapor device for each oven
  • Loader-friendly

SPECIFICATION

  • Special baking stones
  • Vapor extraction hood with fan
  • Stainless steel doors
  • Priority circuit (oven before vapor)
  • Separate vapor device per oven
  • Vapor relief flaps, accessible from the front
  • Individually replaceable heating elements
  • Prepared for external load breaking (oven and vapor device separately)


OPTIONS

  • Steam condenser
  • WP POWERMANAGEMENT
  • WP INTELLIGENT ENERGY CONTROL (WP IEC)
  • JACK manual loader
  • Networking via WP OVEN-CONTROL
    - Remote diagnosis via the internet
    - Screen operation via the internet
    - Networking of single ovens
    - Master slave

Products

  • Bread
  • Pan bread
  • Toast
  • Rolls
  • Pastries

Capacity

  • Baking aerea from 4 - 8 m²
